Key Features

• 6MP High-Resolution Imaging
• Maximum Resolution: 3200 × 1800
• Powered-by-DarkFighter Technology
• Deep-Learning Human & Vehicle Classification
• 1/2.4" Progressive Scan CMOS Sensor
• Ultra-Wide F1.0 Aperture
• Ultra-Low 0.001 Lux Colour Sensitivity
• 120dB True WDR
• Smart IR Night Vision
• 2I Version: Up to 60m IR
• 4I Version: Up to 80m IR
• 850nm Infrared Illumination
• Intelligent Perimeter Protection
• Face Capture
• 2.8mm or 4mm Fixed Lens Options
• H.265+ Video Compression
• Multiple Video Streams
• microSD Storage up to 512GB
• Hik-Connect Support
• ONVIF Profiles S, G & T
• PoE Connectivity
• IP67 Weather Resistance
• Robust Metal Construction
• Indoor & Outdoor Applications

6MP High-Resolution Imaging

The DS-2CD2T66G2H-2I/4I captures surveillance footage at a maximum resolution of:

3200 × 1800

At full 6MP resolution, the camera supports up to:

20fps @ 3200 × 1800

For Australian 50Hz systems, it also supports up to:

25fps @ 2688 × 1520

as well as 1920 × 1080 and 1280 × 720.

The 6MP resolution provides an excellent balance between image detail, recording storage and network bandwidth.

High-resolution footage can assist when reviewing:

• People
• Clothing
• Vehicles
• Driveways
• Building Entrances
• Property Activity
• Commercial Areas
• Objects
• Security Incidents

Powered-by-DarkFighter Technology

The DS-2CD2T66G2H-2I/4I incorporates Hikvision's Powered-by-DarkFighter technology, designed to provide excellent image performance under challenging low-light conditions.

Hikvision specifies minimum illumination of:

Colour: 0.001 Lux @ F1.0, AGC ON

B/W: 0 Lux with IR

This makes the camera particularly suitable for areas where ambient lighting is limited.

Ultra-Wide F1.0 Aperture

The camera features an ultra-wide F1.0 aperture, allowing more available light to reach the image sensor.

Combined with Powered-by-DarkFighter technology, the bright F1.0 optics help improve low-light image quality and retain valuable image detail.

Typical applications include:

• Long Driveways
• Car Parks
• Warehouses
• Building Perimeters
• Commercial Properties
• Loading Areas
• Industrial Sites
• Low-Light Outdoor Areas

Deep-Learning Human & Vehicle Classification

The DS-2CD2T66G2H-2I/4I uses deep-learning technology to classify supported security targets as:

• Humans
• Vehicles

This allows supported security events to focus on important targets instead of treating all movement within the scene equally.

It can help reduce unnecessary security events caused by:

• Animals
• Leaves
• Rain
• Shadows
• Changing Lighting
• Other Non-Target Movement

Intelligent Motion Detection

Motion detection supports alarm triggering according to specified human and vehicle target types.

When correctly configured with a compatible Hikvision NVR or surveillance platform, this can help improve:

• Event Accuracy
• Security Notifications
• Recorded Event Searching
• CCTV Monitoring Efficiency

Intelligent Perimeter Protection

The camera supports intelligent perimeter functions including:

• Line Crossing Detection
• Intrusion Detection
• Region Entrance Detection
• Region Exit Detection

These events support alarm triggering according to specified human and vehicle targets.

Professional installers can use these functions to monitor:

• Driveways
• Gates
• Property Boundaries
• Building Perimeters
• Restricted Areas
• Car Parks
• Loading Areas
• Commercial Sites

Face Capture

The DS-2CD2T66G2H-2I/4I also supports face capture.

Face capture should not be confused with facial recognition. The camera can capture facial images, while identification against a face database requires compatible back-end equipment and appropriate system configuration.

120dB True Wide Dynamic Range

The camera incorporates 120dB True WDR, helping retain useful image detail when bright and dark areas appear simultaneously within the monitored scene.

This is particularly useful around:

• Building Entrances
• Warehouse Doors
• Garage Entrances
• Loading Areas
• Covered Driveways
• Areas Facing Bright Daylight
• High-Contrast Indoor/Outdoor Scenes

Long-Range Smart IR Night Vision

One of the strongest features of the DS-2CD2T66G2H series is its extended infrared night vision.

The camera uses 850nm infrared illumination with Smart Supplement Light technology.

DS-2CD2T66G2H-2I

Provides Smart IR illumination up to:

60 metres

DS-2CD2T66G2H-4I

Provides extended Smart IR illumination up to:

80 metres

This makes the full-size bullet camera particularly suitable for applications where longer night-time coverage is required.

2I vs 4I

DS-2CD2T66G2H-2I

• Up to 60m Smart IR
• Lower maximum power consumption
• Ideal for medium-to-long-range outdoor surveillance

DS-2CD2T66G2H-4I

• Up to 80m Smart IR
• Extended night-time surveillance distance
• Ideal for larger sites and longer perimeter areas

The correct version should be selected according to the required surveillance distance and installation environment.

Ideal Long-Range Applications

The extended IR performance makes this camera particularly suitable for:

• Long Driveways
• Large Residential Properties
• Car Parks
• Warehouses
• Industrial Sites
• Commercial Yards
• Loading Areas
• Building Perimeters
• Property Boundaries
• Rural Properties

2.8mm & 4mm Fixed Lens Options

The DS-2CD2T66G2H-2I/4I is available with 2.8mm and 4mm fixed lens options.

2.8mm Lens

Approximate field of view:

• Horizontal: 114.8°
• Vertical: 60°
• Diagonal: 143.5°

This wider lens is generally suitable for:

• Driveways
• Building Frontages
• Car Parks
• Yards
• Wide Perimeter Areas
• General Outdoor Surveillance

4mm Lens

Approximate field of view:

• Horizontal: 94°
• Vertical: 50.2°
• Diagonal: 112°

The 4mm lens provides a narrower field of view for more concentrated surveillance.

DORI Distance

Hikvision specifies approximate DORI distances of:

2.8mm Lens

• Detect: 64m
• Observe: 25m
• Recognise: 12m
• Identify: 6m

4mm Lens

• Detect: 77m
• Observe: 30m
• Recognise: 15m
• Identify: 7m

Actual performance depends on camera position, installation height, lighting, target movement and environmental conditions.

H.265+ Video Compression

The DS-2CD2T66G2H-2I/4I supports Hikvision's efficient H.265+ video compression technology.

Supported video compression includes:

• H.265+
• H.265
• H.264+
• H.264
• MJPEG on the supported sub-stream

Video bit rate is configurable from:

32 Kbps to 16 Mbps

Efficient compression can help reduce network bandwidth and recording storage requirements.

Multiple Video Streams

The camera supports:

• Main Stream
• Sub-Stream
• Third Stream under supported settings

Multiple streams allow different settings to be used for:

• High-Resolution NVR Recording
• Remote Viewing
• Mobile Viewing
• Secondary Monitoring
• Bandwidth Management

microSD Storage up to 512GB

The camera incorporates an onboard memory card slot supporting:

• microSD
• microSDHC
• microSDXC

with capacity up to:

512GB

This can provide edge storage for applications such as:

• Event Recording
• Backup Recording
• Standalone Camera Applications
• Additional Recording Resilience
• Network Interruption Protection

Memory card sold separately.

Automatic Network Replenishment

The camera supports ANR – Automatic Network Replenishment when used with compatible equipment.

ANR can help recover video stored at the camera following a temporary network interruption, providing additional recording resilience in professionally configured systems.

Hik-Connect Remote Access

The DS-2CD2T66G2H-2I/4I supports Hik-Connect.

When connected to a compatible Hikvision surveillance system and correctly configured, remote functionality can include:

• Live Viewing
• Recorded Playback
• Event Monitoring
• Security Notifications
• Remote CCTV Access

ONVIF & Professional Integration

The camera supports:

• ONVIF Profile S
• ONVIF Profile G
• ONVIF Profile T
• ISAPI
• SDK
• ISUP

This provides flexibility for professional Hikvision and compatible third-party CCTV system integration.

PoE Connectivity

The DS-2CD2T66G2H-2I/4I supports:

IEEE 802.3af PoE – Class 3

This allows camera power and network data to be carried through a single compatible Ethernet cable.

The camera can therefore connect directly to:

• Hikvision PoE NVRs
• Compatible PoE Network Switches
• Professional IP CCTV Networks

Power Requirements

2I Version

• 12V DC ±25%
• Maximum DC Consumption: 8.4W
• PoE: IEEE 802.3af Class 3
• Maximum PoE Consumption: 10W

4I Version

• 12V DC ±25%
• Maximum DC Consumption: 10W
• PoE: IEEE 802.3af Class 3
• Maximum PoE Consumption: 12.5W

The 4I version requires slightly more power due to its extended infrared illumination.

IP67 Weather Resistance

The DS-2CD2T66G2H-2I/4I carries an IP67 water and dust resistance rating, making it suitable for properly installed outdoor CCTV applications.

Typical installations include:

• Residential Properties
• Commercial Buildings
• Warehouses
• Car Parks
• Industrial Sites
• Loading Areas
• Long Driveways
• Property Perimeters

Robust Metal Construction

The camera features:

• Metal Front Cover
• Metal Body
• Metal Bracket

Approximate dimensions:

286.7 × 93.3 × 91.2mm

Approximate weight:

1.12kg

Operating temperature:

-30°C to +60°C

This robust full-size construction makes the camera well suited to professional outdoor surveillance installations.

Flexible Camera Adjustment

The mounting system provides:

• Pan: 0° to 360°
• Tilt: 0° to 90°
• Rotation: 0° to 360°

This provides flexibility when positioning the camera for walls, ceilings and other suitable mounting surfaces.

Main Specifications

• Model: DS-2CD2T66G2H-2I/4I
• Camera Type: Fixed Bullet Network Camera
• Technology: Powered-by-DarkFighter
• Resolution: 6MP
• Maximum Resolution: 3200 × 1800
• Maximum Full-Resolution Frame Rate: 20fps @ 3200 × 1800
• 50Hz Frame Rate: Up to 25fps @ 2688 × 1520
• Image Sensor: 1/2.4" Progressive Scan CMOS
• Minimum Colour Illumination: 0.001 Lux @ F1.0, AGC ON
• B/W Illumination: 0 Lux with IR
• Lens Options: 2.8mm / 4mm Fixed
• Aperture: F1.0
• 2.8mm Horizontal FOV: 114.8°
• 4mm Horizontal FOV: 94°
• WDR: 120dB
• Supplement Light: IR
• IR Wavelength: 850nm
• 2I IR Range: Up to 60m
• 4I IR Range: Up to 80m
• Smart Supplement Light: Yes
• Human Classification: Yes
• Vehicle Classification: Yes
• Deep Learning: Yes
• Line Crossing: Yes
• Intrusion Detection: Yes
• Region Entrance Detection: Yes
• Region Exit Detection: Yes
• Face Capture: Yes
• Video Compression: H.265+ / H.265 / H.264+ / H.264
• Video Bit Rate: 32 Kbps to 16 Mbps
• Local Storage: microSD up to 512GB
• ANR: Supported
• Hik-Connect: Supported
• ONVIF: Profiles S, G & T
• Network: RJ45 10/100Mbps Ethernet
• PoE: IEEE 802.3af Class 3
• Weather Protection: IP67
• Construction: Metal Front Cover, Body & Bracket
• Dimensions: 286.7 × 93.3 × 91.2mm
• Weight: Approx. 1.12kg
• Operating Temperature: -30°C to +60°C
• Application: Indoor & Outdoor

Ideal For

• Residential Homes
• Large Residential Properties
• Long Driveways
• Commercial Properties
• Warehouses
• Industrial Sites
• Car Parks
• Loading Areas
• Building Perimeters
• Property Boundaries
• Commercial Yards
• Rural Properties
• Low-Light CCTV Applications
• Long-Range Night Surveillance
• Professional Indoor & Outdoor CCTV Systems

Benefits

• High-detail 6MP surveillance
• Powered-by-DarkFighter low-light technology
• Ultra-wide F1.0 aperture
• Excellent 0.001 Lux colour sensitivity
• Deep-learning human and vehicle classification
• Intelligent perimeter protection
• Face capture
• 120dB WDR
• Long-range Smart IR
• Up to 60m IR with 2I
• Up to 80m IR with 4I
• H.265+ compression
• Up to 512GB microSD storage
• Automatic Network Replenishment support
• Hik-Connect remote access
• ONVIF integration
• Standard IEEE 802.3af PoE
• IP67 weather resistance
• Robust metal construction
• Professional long-range bullet design

The Hikvision DS-2CD2T66G2H-2I/4I 6MP Powered-by-DarkFighter Fixed Bullet Network Camera provides an excellent combination of high-resolution imaging, advanced low-light performance, intelligent target classification and long-range infrared surveillance.

With 6MP resolution, F1.0 optics, 0.001 Lux colour sensitivity, deep-learning human/vehicle classification, 120dB WDR, microSD storage and Smart IR up to 60m or 80m, it is particularly well suited to professional residential, commercial and industrial CCTV systems requiring reliable long-range night surveillance.

DS-2CD2T66G2H-2I/4I
